Bench Scale KERN FCB 12K1-2024a

Bench scale with second display on the backside of the scale

List price
220.00 €

Weighing capacity

12000 g

Readability

1 g

Standard Option
Description
  • PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
  • Practical second display on the back of the balance
  • High mobility: Thanks to battery operation/rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
  • Data interface RS-232 as standard
  • Protective working cover included with delivery
Specifications

Article codes, product groups & Status information

Model article-code
:
FCB 12K1-2024a
Model-Serie
:
FCB
Assortment
:
KERN
Product Type
:
Food scales
Product group
:
Bench scales
Product usage type
:
Main article
EAN code (Model)
:
4045761202641
Predecessor Model
:
FCB 12K1-2017a
Successor Model
:
FCB 12K1
Planned start date
:
2018-1HJ
Customs tariff number
:
84238129
Product status
:
Active

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
1167 g
Packaging component - by weight - plastics
:
22 g
Packaging component - by weight - styrofoam
:
384 g
Packaging component - by weight - foam
:
74 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
340×405×185 mm
Gross weight
:
3.4 kg
Net weight
:
2.8 kg
Shipping method
:
Parcel service

Technical data - Primary

Weighing capacity
:
12000 g
Readability
:
1 g

Technical data - Display

Display height
:
25 mm

Technical data - Power supply

Battery
:
9 V Block
Operating time
:
12 h
Mains adapter/adapter included
:
CH;EURO;UK;US
Charging time
:
10 h
Input Voltage
:
220 V - 240 V AC, 50 Hz
Operating time (Backlight off)
:
10 h
Rechargeable battery
:
Rchrg. battery optional

Technical data - Counting data

Counting resolution
:
6000
Mininum piece weight at piece counting (Laboratory)
:
2 g
Minimum piece weight
:
20 g

Technical data - Verification

Verification approval conforming to 2014/31/EU
:
Yes

Responsible Persons

Product manager
:
Steffen Hofmann

Prices & Discounts

List price
:
220.00 €
Warranty
:
24 mon

Technical data - Construction

Material weighing plate
:
Stainless steel
Revolving screw feet
:
Yes
Weighing surface (d)
:
253×228 mm
Dimensions of weighing plate (W×D)
:
253×228 mm
Material casing
:
Plastic

Technical data - Measuring system

Calibration method
:
Adjusting with external weight
Linearity
:
± 3 g
Readability
:
1 g
Recommended adjusting weight
:
12 kg (M1)
Repeatability
:
1 g
Weighing units
:
Dwt;ffa;g;kg;lb;mo;oz;ozt;tl (HK);tl (Tw);tol
Weighing system
:
Strain gauge

Technical data - Environmental conditions

Maximum humidity
:
80 %
Maximum operating temperature
:
35 °C
Minimum ambient temperature
:
5 °C

Optional Services

DAkkS Calibration
:
963-128
